Mars Fuse Cartridge 30A 82138

The Mars 82138 is a 30 amp cartridge fuse for branch circuit and equipment protection in HVAC, refrigeration, and general electrical distribution.

Cartridge fuses are the standard overcurrent device in fused disconnect switches, safety switches, and fuse blocks serving mechanical equipment. The cylindrical body seats in spring clips or bolted terminals, providing a secure, low-resistance connection that tolerates the thermal cycling normal to motor loads. Compared with plug fuses, cartridge construction offers higher interrupting ratings and a much wider range of amperage and voltage classes.

At 30 amps, this fuse typically protects smaller condensing units, fan and pump motors, control transformers, heater circuits, and equipment subfeeds.

Applications include fused disconnects at outdoor air conditioning and heat pump units, refrigeration condensing unit protection, motor branch circuits, unit heater and duct heater feeds, and general commercial and industrial distribution.

Correct replacement requires more than matching amperage. The fuse class determines interrupting rating and time-current characteristic, and equipment is listed for use with specific classes. A time delay fuse in a motor circuit must not be replaced with a fast-acting type, which will open on startup inrush, and the interrupting rating must exceed the available fault current at the installation point.

Verify the class designation, voltage rating, physical dimensions, and time delay characteristic against the fuse being replaced. De-energize and lock out the circuit, confirm absence of voltage with a meter, and inspect the fuse clips for heat discoloration or loss of spring tension before installing the replacement.

Brand

Mars

SKU

82138

Category

Fuses

Weight

0.17 lbs

Dimensions

5.00" x 0.81" x 0.81"

Price

$29.00

Availability

In stock (6 available)

Rating

0 / 5.0
